DOORS FOR GLASS

DOORS FOR GLASS
These Doors Require Edge Treatments:
Stile/Rail & Outside Edge Profiles.
Standard Lead-Times are 2 Weeks/Un-Finished & 3 Weeks/Pre-Finished for 12+ Doors
GLASS NOT INCLUDED - ALL 3/4" thick.

All doors shown are available in any wood specie shown below in the pricing table.
Use color code to figure sq. ft. prices shown in table below
All available Un-Finished or Pre-finished in any of our colors See: Colors For Finished Doors

Glass Doors will be prepared to accept glass in one of two ways:
Diagram A:
SR-10G - SR-20G - SR-30G (Stile & Rail Profiles)
Prepared for 1/8" Glass
1. Routing for Clear Vinyl Retainer (see diagram A).
This is our standard procedure to prep for glass unless otherwise specified.
The vinyl retainer will automatically be supplied at no extra charge
and is available in clear only.
2. Squaring out the back of the door will only be done only if requested and will require glass clips (clips are not supplied.) Note; Arched doors that are squared out for glass will require an arched piece of glass to be used. (Glass not included)

#301-G

Minimum Size:
7 1/4" x 5 1/2"

Color Code:
RED

#302-G

Minimum Size:
8" x 7 1/2"

Color Code:
BLUE

#303-G

Minimum Size:
8" x 6 3/4"

Color Code:
BLUE

Any of our doors shown at Raised Panel Doors can be made open for
glass by adding a "G" at the end of the doors style. For mullion doors tell us the number of lites you would like as well as the mullion style as shown below.

Diagram B:

Available in Most Profiles
Prepared for 1/8" Glass
*You must enter in the mullion style you need or it will be done as SR-30,
even if your Stile & Rail is a different style.

Mullion Styles

The standard placements of mullions will be to divide the opening equally as follows:
8� high to 22� high=4 lites
22-1/16� high to 38� high=6 lites
38-1/16� high to 60� high=8 lites

Special mullion placements are available.
Please send detailed drawings for price and availability.

Profile MR-40 will have the mullions shipped loose and
must be held behind the glass.

Soft Maple, White Ash, White Oak, and Walnut doors will be made with
square/flat mullions (SR-30). Mullions profiled with SR-10 or SR-20
will have a setup charge added.
Glass Not Included

#301-WG

Minimum Size:
7 1/2" x 7 1/2"

Color Code:
RED
+ add $7.00 per lite

#302-WG

Minimum Size:
8" x 8 1/4"

Color Code:
BLUE
+ add $7.00 per lite

#303-WG

Minimum Size:
8" x 8 1/4"

Color Code:
BLUE
+ add $7.00 per lite

#390-WG

Minimum Size:
14" x 14"

Quote Only

#391-WG

Minimum Size:
14" x 18"

Quote Only

DOORS FOR GLASS PRICING (per square foot)
Color Code	*Red Oak	*Hard Maple	*Cherry	*Alder	*Hickory	White Birch	White Oak	Clear Pine
RED	$12.93	$13.70	$15.93	$13.89	$13.31	$13.60	$13.52	$14.30
BLUE	$14.39	$15.16	$17.39	$15.35	$14.77	$15.06	$14.98	$15.76

Color Code	*Knotty Pine	Soft Maple	*Paint Grade (Sound Birch)	White Ash	Walnut	Rustic Alder	Rustic Cherry	Rustic Hickory
RED	$14.18	$13.39	$12.44	$13.52	$17.86	$13.82	$16.73	$14.29
BLUE	$15.64	$14.85	$13.90	$14.98	$19.69	$15.28	$18.19	$15.75
NOTE: Mullion Doors add $7.00 per lite Doors are priced at a 1 sq. ft. minimum Indicates species available in 5/4 stock-add 25% to wood cost. (Square edges only) Other species available by quote only: Beech European, Red Birch, Butternut, Cedar, Lyptus, Genuine Mahogany, African Mahogany, Rustic Maple, Birdseye Hard Maple, Red Oak Quarter Sawn, White Oak Quarter Sawn, Red Oak Rift, White Oak, Poplar. For Premium Grade Add 20% To The Un-Finished Door Cost. For description on "Premium Grade" See Pricing Info* For your Fast easy quote with extra discounts, use our: Door Quote/Order Form

How To Calculate Cost For Glass Doors:
*Note: Send us your info for extra discounts and quick quotes. Use one of our forms:
*Use our online form: Door Quote/Order Form Or our fax in form: Door Quote/Order Form
*For more information on how to Calculate Cost and Measuring: CLICK HERE
*Measurements are rounded to the next highest inch.
*Round all calculations to the next highest hundredth. (1 sq. ft. minimum per door)
*Center rails are added for doors over 23" wide or 60" high unless otherwise requested.

HOW TO PRICE:
1. Measure your door, Length x Height in inches.
2. Divide by 144, = Square Footage.
3. Multiply the Square Footage by the cost for the type of wood you need.
(Door Cost is shown above in the pricing table, use the color code for for door style.)
4. All prices are for 12 or more doors. 4 or less add 35%, 11 or less add 20%.
5. For mullion doors, add $6.65 per lite.
6. Also add in extras such as:

Finishing with Clear-coat:                                     $6.85 / sq. ft. (See Colors For Finished Doors)
Finishing with Paint:                                              $12.45 / sq. ft.
5/4 Thick                                                                 add 25% to wood cost
5/4" = (1" Finish Thickness, E-104 edge only)-(Red Oak, Maple & Cherry Only)
Premium Grade Lumber                                      add 20% to un-finished cost

One Piece MDF Glass and Mullion Doors
MDF is Medium Density Fiberboard. (Paints very well)
These Doors are made of a Solid MDF Material.
**SR-20 is the only Mullion and inside edge offered on our MDF Glass Doors**
