DOOR
& DRAWER OUTSIDE EDGE PROFILES |
ALL NEW PILLOW EDGE NOW AVAILABLE BY
QUOTE
E-129
![](images/Doors/Pillow%20Edge_small.jpg) |
These outside edge profiles are
available on all Raised Panel and Flat Panel Doors.
For other door
styles, see that page for details.
5/4 thick materials can only use E-104.
If you need Hinge Bore done, please pick one of the
profiles that allow the Hinge Boring.
*For Profiles E-103 & E-107 you MUST Measure door at 1/2" Larger than
opening |
E-101
![](images/Doors/drawer1.gif) |
Hinge Bore for
Concealed Hinges is available |
|
E-102
![](images/Doors/outsid24.gif) |
Must use 5/8"
or more
Overlay for Concealed Hinges |
|
E-103
![](images/Doors/drawer3.gif)
|
Hinge Bore
NOT available |
|
E-104
![](images/Doors/drawer4.gif) |
Hinge Bore for
Concealed Hinges is available
*This profile only for 5/4"
Also used on 3/4" |
|
E-105
![](images/Doors/outsid25.gif) |
1/4"
radius edge.
Drilling for Concealed Hinges is available |
|
E-106
![](images/Doors/drawer6.gif) |
Hinge Bore for
Concealed Hinges is available |
|
E-107
![](images/Doors/outsid26.gif)
|
Hinge Bore
NOT available |
|
E-108
![](images/Doors/drawer8.gif)
|
Hinge Bore
NOT available |
|
E-109
![](images/Doors/outsid27.gif)
|
Hinge Bore at 7/16" Depth only.
*Use Compact 38
Blum Hinges |
|
E-110
![](images/Doors/drawer10.gif)
|
Hinge Bore for
Concealed Hinges is available |
|
E-111
![](images/Doors/outsid28.gif)
|
Hinge Bore
NOT available |
|
E-112
![](images/Doors/outsid29.gif)
|
Hinge Bore
NOT available |
|
E-113
![](images/Doors/outsid30.gif)
|
Hinge Bore
NOT available |
|
E-114
![](images/Doors/drawer14.gif) |
Hinge Bore for
Concealed Hinges is available |
|
E-115
![](images/Doors/E-115.jpg)
|
Hinge Bore for
Concealed Hinges is available |
|
E-116
![](images/Doors/drawer15.gif)
|
Hinge Bore
NOT available |
|
E-117
![](images/Doors/drawer16.gif) |
Hinge Bore at 7/16" Depth only.
*Use Compact 38
Blum Hinges |
|
E-118
![](images/Doors/drawer17.gif) |
Hinge Bore at 7/16" Depth only.
*Use Compact 38
Blum Hinges |
|
E-121
![](images/Doors/outsid32.gif) |
3/8"
R.
Hinge Bore
for Concealed Hinges is available |
|
E-122
![](images/Doors/drawer20.gif) |
Mitered Doors & Slab Style Drawer Fronts Only.
Drilling for Concealed Hinges is available |
|
E-123
![](images/Doors/E-123.jpg) |
1/8" R.
Hinge Bore
for Concealed Hinges is available |
|
E-124
![](images/Doors/E-124.jpg) |
1/8" R.
Hinge Bore
for Concealed Hinges is available |
|
E-126
![](images/Doors/E-126.jpg) |
Hinge Bore at 7/16" Depth only.
*Use Compact 38
Blum Hinges |
|
E-127
![](images/Doors/E-127.jpg) |
Hinge Bore
for Concealed Hinges is available |
|
E-129
![](images/Doors/E-129.jpg) |
Hinge Bore
NOT
available |
